CARDIN DKS250

CARDIN DKS250 is a wired control system with a vandal-proof metal structure made of zamac, which guarantees it a very high resistance to wear.

Extremely efficient and easy to install, CARDIN DKS250 consists of a vandal-proof numeric selection keypad and an interface, connected to each other by a shielded unipolar cable.

The DKS250 system allows the actuation, via cable, of electrical and electronic devices that require high security for access, such as your motorized doors.

The DKS250 system also offers the possibility to register codes remotely, without having to access the interface, simply by entering a specific validation code and using up to three keypads connected to a single interface to issue commands from different locations.

Even better, it is possible to manage, with separate keys, up to four different functions, using contacts in pulse mode. The keypad stands out for the reliability of its robust and durable zamac metal structure.

It features a single-piece silicone rubber sealing gasket, a zamac wall mounting plate, and a locking system with a custom screw element. The robustness of the housing and its sealing characteristics make it perfectly suited for optimal outdoor use.

CARDIN DKS 250 can memorize up to 250 user codes and has functions for erasing and memorizing codes directly on the keypad and resetting the memory.

In normal use, the system allows, after entering the correct code, to issue up to four commands. After 5 seconds from the last command, the system automatically invalidates the commands while waiting for a new code validation. The channels (functions) can be activated one at a time, and activation occurs in dead-man mode, with no time limit.

The kit consists of: – 1 keypad + 1 interface

TECHNICAL DESCRIPTION DKS250T:

Dimensions: 72 x 104 x 26

The keypad consists of a vandal-proof metal structure made of zamac, high-resistance paint, and wear-resistant chrome keys. Easy to install, it has an IP57 protection rating and a vandal-proof mounting system with special screws and keys. It features:

– Red signaling LED

– Green signaling LED

– 10 numeric keys (0-9)

– One confirmation key *

– One operation cancellation key #

– 4 channel functions (A, B, C, D)

– Sound alarm.

TECHNICAL DESCRIPTION DKS250R:

Dimensions: 95 x 75 x 25

The interface, housed in a small plastic casing, is easy to install; it is organized as follows:

– 4 N.O. relays (one for each channel),

– 1 multifunction key that allows:

– memorizing a code, erasing a code, erasing all memory, entering a validation code for “remote memorization.”

It is possible to memorize 250 codes of a maximum of 6 digits and to validate, for each code, from one to four channels.

As a guarantee of quality and to fully satisfy its customers, Alloremotecontrol offers a one-year warranty on all its products. Even better, you can opt for a second year of additional warranty at the time of placing your order (see T&Cs).

WARNING: After entering 5 incorrect codes, the interface locks the entire system (one or more keypads) for one minute (a power cut does not reduce this time, which is recorded).
